Steveco 2 pole contactor type 122, 24V coil, 30 amp lot

We Have Thousands of products available.
o Electronic and mechanic motor protection devices
o Medium voltage soft starters
o AC and DC variable speed drive packages
Transformers Ventilation equipment Phase converters
o Phase converters convert single phase to three phase Multiple motor loads in excess
o 1 and 2 bearing generators to 2000kw o PTO drive generator sets 10 to 160kw
o High-speed gas air-cooled sets
o AC & DC metering (volts, amps, hour, frequency, pf, kw); Analogue and digital
o Safety switch engine safety and annunciator components
Power Factor Correction Technology
Steveco 2 Pole Contactor Type 122, 24V Coil, 30 amp
Description: 2POL CONTACTOR 24V
American Express, Money Order, Cashier's cheque
Designed for Air Conditioning and Heating Equipment
* Low VA coil for cooler operation and increased life.
* Universal style mounting bracket fits existing mounting holes.
* Double break contacts ensure positive make and break.
* Screw terminals or pressure connectors and double 1/4” quick connects provided on all models for easy installation.
Insulating Material: Contact block and carrier are high quality electrical-grade thermosetting resin
Temperature Range: –40°F to 150°F
Mechanical Life: Conforms to UL and ARI specifications
Electrical Life: Conforms to UL and ARI specifications
Agency: U.L. file number E75492, C.S.A. file number LR49598
Coil Insulation: Class B (130°C)
Termination: Pressure Connectors and Double 1/4” Q.C.
Operate: 85% of nominal coil voltage; 110% maximum safe operate
Approximate Overall Dimensions: 31/4 in. x 2 in. x 25/8 in.
